Maximum working pressure: 100 psi

Minimum burst pressure: 300 psi

Rated flow: 6.44 L/min

Maximum leakage: ≤ 0.03 mL

Pressure-tolerant plug-in and pull-out pressure: ≤ 50 psi

Maximum insertion force without pressure: ≤ 65 N

Mechanical life: At least 5,000 insertions and withdrawals

Operating temperature: 10°C to +65°C

Storage temperature: -40°C to +75°C

Working medium: Deionized water, ethylene glycol, propylene glycol

Body material: SUS; Sealing ring: EPDM
